High Precision Linear Weighing Packing Machine For Almond

Model: LD-320AS

Application:

Suitable for packing all kinds of grain material, sheet material, strip material, and abnormity material such as almonds, nuts, hazelnut, peanut, pistachio, macadamia nut, cashew, sunflower seeds, peanut, etc.

E-mail: [email protected]

Tel/Whtasapp: +86 173 8860 2385

Get Price Send Email
  • Application
  • Description
  • Features
  • Videos

Application:

High precision linear weighing packing machine(LD-320AS) for almond, can quickly automate the packaging process and improve production efficiency.

Examples:

Almonds, nuts, hazelnut, peanut, pistachio, macadamia nut, cashew, sunflower seeds, peanut, etc.

Kindly Reminder:

Please tell us the following information when you send us an inquiry. Based on your message, we will suggest the optimum solution to you for reference. Thank you.
1. Your product
2. Product weight
3. Foil Bag/ Gusset Bag/ Sachet dimension
4. Foil Bag/ Gusset Bag/ Sachet material

Packaging Exambers:

High Precision Linear Weighing Packing Machine For Nut Cashew

Model LD-320LD-380
Film width 120-320mm180-380mm
Bag length50-200mm60-280mm
Bag width50-150mm60-180mm
Diameter of film roll Max.300mmMax.320mm
Packing speed35-70bags/min
Measuring range50-500ml50-750ml
Film thickness 0.04-0.07mm
Power220V 50/60Hz 2.2KW220V 50/60Hz 2.5KW
Machine size(L*W*H)970*680*1950mm1100*800*2150mm
Machine weight About 300kgAbout 450kg

1. Products dosing, Filling, Laminate heat sealable pouch making and sealing;

2. Stainless steel 304 structure and surface;

3. Weighing and Packaging PLC & HMI Control Integrated, More stable operation, Easy for parameter setting;

4. Simple changing of pouch former, to adapt different pouch size requirements;

5. Intelligent temperature controlling configuration, ensure the artistic and neat sealing;

6. Configure with packaging film pre-pulling device, to enable stable pouch making;

7. easy to change the packaging film;

8. Mesure at high accuracy: The weigher weight of the material;

9. Take up the small place, Match the small weigher, elevator, and support platform, take up little place;

10. Cost-effective, Compare with the LD-420 main packer, the LD-320 model could reach the demand for snack packing at a low cost.

We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
