Automatic Candy Horizontal Flow Wrapper Packing Machine With Sorting Function
Model: LD-350B
Application:
It is suitable for high-speed pillow packing of square, spherical, disc, cylindrical, button, oval and all kinds of special shape and fixed shape block candies.
Application:
Automatic candy horizontal flow wrapper packing machine with sorting function, It is suitable for high-speed pillow packing.
Examples:
Candy, biscuit, toffee, vegetables, fruits, chocolate, snacks, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Exambers:
| Model | LP-350 | LP-400 | LP-450 | LP-600 |
| film width | max.350mm | max.400mm | max.450mm | max.600mm |
| bag length | 65-330mm | 150-400mm | 150-450mm | 160-500mm |
| bag width | 50-160mm | 50-180mm | 50-180mm | 100-280mm |
| high end products | max.60mm | max.65mm | max.75mm | max.110mm |
| film roll diameter | max.320mm | max.320mm | max.320mm | max.320mm |
| packing speed | 40-180bag/min | 30-150bag/min | 30-150bag/min | 20-150bag/min |
| Force | 220V 50/60Hz, 2.6KW | 220V 50/60Hz, 2.8KW | 220V 50/60Hz,2.8KW | 220V 50/60Hz, 2.8KW |
| Machine size (length x width x height) | 4030*770*1420 | 4030*770*1420 | 4030*820*1420 | 4030*970*1500 |
| Machine weight | about 580kg | about 600kg | about 650kg | about 680kg |
| optional devices | 1. Side feeding device, 2. Straight feeding device, 3. Material conveyor belt,4. Final sealing auxiliary conveyor, 5. Auxiliary material feeding device, 6. Material cutting prevention device, 7. Perforation device, 8. Angle folding device, 9. Date printer, 10. Labeler | |||
1.Dual frequency conversion control, the length of the bag can be set and cut in one step, saving time and movies.
2.The interface features are easy and quick to set up and operate.
3.Self-diagnosis fault function, clear fault display.
4.High-sensitivity photoelectric eye color tracking, cut-seal position numerical input for higher accuracy.
5.Temperature independent PID control, more suitable for packing different materials.
6.Positioned stop function, no knife or film waste.
7.Simple driving system, reliable operation, convenient maintenance.
8.All control is through software, easy to adjust and update technically.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
