Automatic Chemical Liquid Premade Pouch Rotary Filling Machine With Storage Hopper
Model: LD-8200L
Application:
Automatic Chemical Liquid Premade Pouch Rotary Filling Machine With Storage Hopper, it is suitable for all kinds of pre-made pouches, and liquid packing, such as chemical liquid, fruit juice, laundry detergent, black pepper sauce, beverage, tomato sauce, peanut butter, jam, etc.
Suitable Pouches:
All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock recloseable bags, stand-up pouch with or without spout ect.
Application:
Automatic Chemical Liquid Premade Pouch Rotary Filling Machine With Storage Hopper, it is suitable for all kinds of pre-made pouches, and liquid packing, such as chemical liquid, fruit juice, laundry detergent, black pepper sauce, beverage, tomato sauce, peanut butter, jam, etc.
Examples:
Bleach, Pesticide, laundry detergent, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Sample:
| Model | LD-8200L |
| No.of working stations | Eight |
| Bags size | W: 100-200mm L: 100-400mm |
| Filling range | 10-2500g depending on type of products |
| Packing speed | 25-60bag/min（speed is determined by the product filling quantity） |
| Total power | 2.5KW |
| Weight | 1400kgs |
| Dimensions | 1140mm X 1500mm X 1560mm（L*W*H） |
| Work flow | giving bag→coding →opening →filling 1 →filling 2→ auxiliary→ exhaust→heat sealing→ .forming and output product |
| Main standard parts | 1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system |
1. Rotor Pump for feeding and measuring the high viscousity Liquid Products.
2. 100L SS316 Storage Hopper for big Tank Liquid Storage No Liquid With Feeding Alarm Function.
3. 8 pre setting Liquid Capacity easy to Operate on the touch screen.
4. Simens PLC Control system keep the full set machine running stable.
5. Rotary doypack machine has the functions of no bag no filling & no filling no sealing.
6.Filling Range from 100ml-2500ml.
7.High Speed 25-40bags per min saving labour cost.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
