Automatic Piston Pump Plastic Bottle Chemical Liquid Filling Machine Line
Model: LD-ALF006
Application:
It suitable for food industry, like chemical, tomato paste, chilli sauce, chemical liquid, butter, ketchup lunch meat, mayonnaise, laundry detergent, shampoo, manmade, etc.
Advantage:
The product adopts advanced general control technology by using PLC touch screen, and intelligent filling to make operation simpler, more convenient, and easier to study, can set the filling amount and filling speed through the touch screen.
Application:
It suitable for food industry, like chemical, tomato paste, chilli sauce, chemical liquid, butter, ketchup lunch meat, mayonnaise, laundry detergent, shampoo, manmade, etc.
Packaging Type:
Bottles, Cans, Tins, etc
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples:
| Model | LD-004 | LD-006 |
| Filling range | 50-1000ml | 50-1000ml |
| Filling speed | <10-25 bottles/min(Base on100-500ml) | <20-35 bottles/min(Base on100-500ml) |
| Measurement accuracy | ±1% | ±1% |
| Power | 380V,220V、50Hz / 2kw | 380V,220V、 50Hz / 2.5kw |
| Gas consumption | 0.6mpa-0.8mpa | 0.6mpa-0.8mpa |
| Weight | 600kg | 650kg |
1. System control, data can be adjusted and stored, simple operation.
2. Use drip proof stainless steel filling head and photoelectric induction.
3. Tracking capping head is controlled by servo motor stable performance and reliable operation.
4. The electric eve uses advanced photoelectricity Easy adjust the position and angle. fast and stable.
5. The connecting shaft connects the motor shaft and the filling support shaft. Stable and easy to install.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
