Automatic 8 Heads Chutneys Thick Sauce Bottle Jar Filling Machine
Model : LD-ALF08
Application :
This machine is suitable for filling liquids, pastes, and sauces, such as chutney, olive oil, peanut butter, soy sauce, chili sauce, chutney, ketchup, mayonnaise, wine, fish sauce, honey, juice, coffee, tea, toner, facial cream, etc.
Application :
This machine is suitable for filling liquids, pastes, and sauces, ideal for cosmetics, pharmaceuticals, food, and chemicals, this robust system ensures consistent fills for viscous or thin liquids, from creams to solvents.
Examples :
Chutney, olive oil, peanut butter, soy sauce, chili sauce, chutney, ketchup, mayonnaise, wine, fish sauce, honey, juice, coffee, tea, toner, facial cream, etc.
Packaging Material :
Glass, Metal, Paper, Plastic, Wood, and Others.
Kindly Reminder :
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Sample :
| Eight Heads Piston Pump Liquid Filling Machine | ||||
| Model | LFZ-04 | LFZ-06 | LFZ-08 | LFZ-10 |
| Filling Range | 50-1000ml (customizable) | 50-1000ml (customizable) | 50-1000ml (customizable) | 50-1000ml (customizable) |
| Production Speed | <15-25 bottles/min | <20-35 bottles/min | <30-40 bottles/min | <40-50 bottles/min |
| Measurement Accuracy | ±1% | ±1% | ±1% | ±1% |
| Power | 2KW | 2.5KW | 3.5KW | 5KW |
| Voltage | 220V, 50Hz | 220V, 50Hz | 220V, 50Hz | 220V, 50Hz |
| Air consumption | 0.6-8Mpa | 0.6-8Mpa | 0.6-8Mpa | 0.6-8Mpa |
| Weight | 600kg | 650kg | 800kg | 800kg |
| Dimension | L4000*W1320*H2090(mm) | L4000*W1320*H2090(mm) | L4000*W1320*H2090(mm) | L4000*W1320*H2090(mm) |
1. The automatic paste filling machine which contact liquid is made of stainless steel 304.
2. This automatic paste filling machine driven by servo motor that ensure filling with high precision and easy adjust for different kinds volume of bottle, like 200ml, 500ml, 1000ml and can put them in same machine.
3. No bottle no filling and no capping.
4. Capping head can easy change to suitable for different cap.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
