Automatic Coffee Bean Premade Pouch Packing Machine
Model: LD-8200A/ 8240A/ 8300A
Application:
Automatic Coffee Bean Premade Pouch Packing Machine(LD-8200A/ 8240A/ 8300A), it is suitable for automatic packing for grain and solid food, such as coffee beans, nuts, dry fruits, candy, cereal, chocolate, biscuit, peanut, capsule, seeds, chemicals, sugar, etc.
Main Process Description:
Bag giving → Date coding → Bag opening → Filling and vibrating 1 → Filling and vibrating 2 → Product settling after filling by vibrating → Heat sealing → Forming and product output
Application:
Automatic coffee bean premade pouch packing machine(ld-8200a/ 8240a/ 8300a), it is suitable for automatic packing for grain and solid food, such as coffee beans, nuts, dry fruits, candy, cereal, chocolate, biscuit, peanut, capsule, seeds, chemicals, sugar, etc.
Suitable Pouches: All type of heat sealable preformed side seal bags, fin seal bags, gusseted bags, block bottom bags, zip-lock recloseable bags, stand-up pouch with or without spout ect.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples:
| Model | LD-8200/LD-8250 |
| Packing material | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc |
| Size | W：70-200/100-250 |
| Filling range | 10-1000g/20-2500g |
| Packing speed | 40-60bag/min（speed is determined by the product filling quantity） |
| Average precision | ≤ ±1% |
| Total power | 2.5KW |
| Dimensions | 1900mm X 1570mm X 1700mm（L*W*H） |
| Work flow | giving bag→coding →opening →filling 1 →filling 2→ auxiliary→ exhaust→heat sealing→ .forming and output product |
| Main standard parts | 1. Code printer 2. PLC control system 3.Bag opening device 4. Vibration device 5.Cylinder 6. Electromagnetic valve 7. Temperature controller 8.Vacuum pump 9. Inverter 10. Output system |
| Optional configuration | 1. Material weighing & filling machines; 2. Platform; 3. Check weigher; 4. Material elevator; 5. Finished product conveyor; 6. Metal detector |
Automatic rotary packing machine adopt precision indexing device and PLC to control each action and working station to make sure the machine operates easily and does accurately.
The speed of this machine is adjusted by frequency conversion with the range, and the actual speed depends on type of products and pouch.
Automatic checking system can check bag situation, filling and sealing situation.
The system shows
no bag feeding, no filling and no sealing.
no bag opening/opening error, no filling and no sealing
no filling, no sealing.
The product and pouch contact parts are adopted stainless steel and other advanced material to guarantee the hygiene of products.
We can customize the suitable one for you according to your requiredment.
Just Tell us : Weight or Bag Size required.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
