Fully Automatic Liquid Detergent Filling And Capping Machine
Model: LD-LFH-04
Application:
Fully automatic liquid detergent filling and capping machine (LD-LFH-04), it is recommended for a wide variety of products including detergent, pesticide, syrup, ketchup, oil, chili sauce, honey, etc.
Advantages:
The filling system is driven by a servo motor which assures high filling accuracy. It is controlled by the PLC, human interface, and easy operation.
Application:
Fully automatic liquid detergent filling and capping machine (LD-LFH-04), it is suitable for filling liquids and pastes of any fluidity in medicine, food, cosmetics and other industries.
Examples:
Detergent, pesticid, syrup, peanut butter, condensed milk, chocolate sauce, ketchup, juice, shampoo, fruit juice, honey, paste, oil, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Sample:
Model | LD-LFH-04 | |||
Filling range | 50-1000ml(Customizable) | |||
Filling speed | <30-40BPM(100-500ml range) | |||
Measurement accuracy | ±1% | |||
Power | 3.5KW | |||
Working power supply | 220V/380V、50Hz | |||
Working pressure | 0.6-0.8MPa | |||
Weight | 850kg | |||
Size | L3800*W1220*H1800(mm) | |||
Stronger PLC software support, may realize the ideal filling operation.
The touching operation color screen, can display the production state, operation procedures and filling ways, tableau objective, operation simple and maintenance convenient.
This China most popular products simplex filler machine jar filling machines automatic liquid filling machine uses vacuum sucking technology to ensure no leakage of filling head during filling production process.
Each filling-head is equipped with a bottle-mouth-clamping device, ensuring the injecting material correct aiming at.
This machine suits for the filling of different sizes of vessel, may change the filling sizes within a few minutes.
Pivotal electrical part use world famous brand such as Mitsubishi, OMRON, SIEMENS.
This machine is equipped with capping machine and labeling machine, which can form a line.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
