High Speed Automatic Dry Tomato Dry Fruit Rotary Doypack Packing Machine
Model : LD-8200/LD-8300
Application :
Suitable for automatic packing of grain and solid food, such as dry tomatoes, dry fruits, nuts, beans, candy, cereal, chocolate, biscuits, peanuts, capsules, seeds, etc. Different kinds of products with stand-up pouches, doypack with zippers, 3-side seal bags, 4-side seal bags, flat bags, etc.
Application :
Suitable for automatic packing of grain and solid food, different kinds of products with stand-up pouches, doypack with zippers, 3-side seal bags, 4-side seal bags, flat bags, etc.
Examples :
Dry tomatoes, dry fruits, nuts, beans, candy, cereal, chocolate, biscuits, peanuts, capsules, seeds, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Exambers:
| Model | LD-8200 | LD-8300 |
| Packing material | 3-side, four edge-sealing bag, self-reliance bag, handbag, spout bags, zipper bag, compound bag, etc | |
| Size | W: 70-200 | W: 200-300 |
| Filling range | 10-1000g | 10-2500g |
| Packing speed | 40-60 bags/min (speed is determined by the product filling quantity)25-40 bags/min (for zipper pouch) | 30-40 bags/min (speed is determined by the product filling quantity)25-35 bags/min (for zipper pouch |
| Average precision | ≤ ±1% | |
| Total power | 2.5KW | 4KW |
| Dimensions | 1900mm*1570mm*1700mm（L*W*H） | 2450mm*1750mm*1450mm（L*W*H） |
| Workflow | 1. Giving bag, 2. Coding date(option), 3. Open zipper, 4. Open the top and bottom, 5. Filling, vibrating (option), 6. The filling product is integrated by vibration, 7. Exhaust(option), closing zipper, sealing, 8. Forming and output | |
1.Flexible Application Range: Suitable for packing a variety of solid forms, including both powders and granules.
2.Compatible with All Pouch Types: Can handle different pre-made pouch styles with ease.
3.User-Friendly Interface: Equipped with a PLC and HMI for simplified operation and control.
4.Quick Pouch Transition: Allows for fast pouch size adjustments in less than 10 minutes.
5.High-Level Automation: Automatically weighs and packs, with built-in alarms to notify users of any errors.
6.Prevention Mechanism: Ensures no filling or sealing occurs unless the pouch is properly aligned, reducing waste.
7.Hygienic Design: Made with SUS304 stainless steel parts that meet GMP standards for safety and cleanliness.
8.Lubrication-Free Bearings: Utilizes imported plastic bearings that require no lubrication and prevent contamination.
9.Energy-Efficient Vacuum System: Operates with low energy consumption and has a long operational lifespan.
10.Reliable Sealing: Offers superior sealing capabilities to enhance the final packaged product.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
