Horizontal Pickled Garlic Pouch Filling Sealing Machine With Linear Weigher
Model: GP-210
Application:
Suitable for packing grains and particles into stand-up pouch doypack pouches premade pouches such as pickled garlic, pickle, kimchi, pickled cucumber, kelp, peanuts, candy, beans, granular medicine, seed, etc.
Application:
Suitable for packing grains and particles into stand-up pouch doypack pouches premade pouches such as pickled garlic, pickle, kimchi, pickled cucumber, kelp, peanuts, candy, beans, granular medicine, seed, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Sample:
| Type | Horizontal Pickled Garlic Pouch Filling Sealing Machine With Linear Weigher | ||
| LDB-200 | LDB-300 | LDB-430 | |
| Bag Material | Multi-layer Composite Premade Bag（e.g.: PET/PE） | ||
| Premade bag type | Vacuum bag, stand-up bag） | ||
| Upgraded Bag Type | (Need additional purchase of functional device) | Gusset Bag, Zipper Bag, box bag (Need additional purchase of functional device | |
| Bag size | 70mm≤W≤150mm | 80mm≤W≤300mm | 80mm≤W≤300mm |
| 70mm≤L≤150mm | 100mm≤L≤300mm | 100mm≤L≤430mm | |
| Speed | 0-60 bags/min | 0-15 bags/min | |
| Sealing Type | Straight grain, pitch is 1mm (Optional reticulate) | ||
| Sealing Width | 10mm (5-20mm) can be customized | ||
| Voltage | 220V, Single-phase, 50/60HZ, 1.2KW | ||
| Air Pressure | 0.65Mpa | ||
| Air Consumption | Standard machine, no additional function | ||
| Body Dimension | 1770*600*1230 mm | 1770*600*1360 mm | |
| Packing Dimension | 1860*710*1550 mm | 1860*710*1650 mm | |
| Export non-fumigation wooden case | |||
1. Versatile Functionality: This machine can handle both pickled garlic vegetables and sauces, allowing separate measurement and packaging. It also offers the flexibility to choose between wet and dry packaging modes.
2. High-Precision Weighing: Equipped with a four-head screw weighing system, it ensures accurate measurements with an error margin of only ±1%. Ideal for measuring pickled garlic vegetables, cassava pearls, and other similar products.
3. Liquid Piston Pump: The machine utilizes a liquid piston pump to measure sauce liquids ranging from 30ml to 300ml. Precise dosing ensures consistent product quality.
4. Vacuum Packaging Capability: It can achieve vacuum packaging, extending the shelf life of products and keeping fresh or frozen items in optimal condition for an extended period.
5. Adaptable Bag Types: The machine accommodates various bag styles. Whether it’s vacuum bags, stand-up pouches, or other formats, it can flexibly adjust the bag length and width to suit your specific packaging needs.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
