Fully Automatic Pharmaceutical Drug Tablet Pill Bottle Counting And Packing Machine
Model: LF-GA-001
Application:
From sorting the drug bottle to labeling the bottle with stickers, our filling line could provide you fully automatic service for your drug package,which suitable for packing gummies, capsules, Drugs, Pills, and so on.
Introduction:
It can be used with bottle unscrambler, capping machine, labeling machine and other equipment to form a fully automatic production line by connecting with it.
Application:
From sorting the drug bottle to labeling the bottle with stickers, our filling line could provide you fully automatic service for your drug package,which suitable for packing gummies, capsules, Drugs, Pills, and so on.
Filling containers: bottles; plastic bottles; glass bottles; tinplate bottles; cartons, etc.
Optional supporting devices: Z-type lifting feeder; bottle unscrambler; capping machine; labeling machine; aluminum foil sealing machine, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples
| Model | LF-GA-001 |
| Filling diameter | 40-130mm |
| Height | 50-200mm |
| Speed | 15-25bottles per minute |
| Material | Stainless steel 304 |
| Control interface | LCD display |
| Origin | 0.6-0.8Mpa |
| Power | 3.8kw |
| Voltage | 220V, 50 / 60Hz |
| Weight | 250kg |
| Size | 2000 * 1000 * 2000mm |
1. All the machines will run synchronously through the PLC system after they are connected, and ensure the stability of long-term operation.
2. The core part of each machine in the production line adopts a modular design to achieve rapid adjustment and independent use.
3. The entire counting production line can achieve simple and rapid assembly and separation.
4. The outer frame of the complete set of machines is made of excellent 304 stainless steel, and the material contact part is made of 316 stainless steel, which fully meets GMP requirements.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
