Semi Automatic Auger Powder Filling Machine
Model: LF-QPJ-01
Application:
Semi Automatic Auger Powder Filling Machine (LF-QPJ-01), It is suitable for loading powdery materials in food, medicine, daily necessities and other industries. Such as powdered and ultra-fine powdered materials such as milk powder, glucose, protein powder, cocoa powder, coffee powder, rice noodles, solid beverages, etc.
Introduction:
The automatic filling machine is designed in accordance with the national GMP standard. This machine can form an assembly line with the bottle unscrambler, capping and capping machine, labeling machine and other equipment.
Application:
Semi Automatic Auger Powder Filling Machine (LF-QPJ-01), It is suitable for loading powdery materials in food, medicine, daily necessities and other industries. Such as powdered and ultra-fine powdered materials such as milk powder, glucose, protein powder, cocoa powder, coffee powder, rice noodles, solid beverages, etc.
Packaging Type: Cans, Tins, Barrel, Bottles, Capsule, Cartons, Stand-up Pouch
Packaging Material: Glass, Metal, Paper, Plastic, Wood, Other.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples
Measuring mode | Auger dosing model(Suitable for power and small granules products ) |
Container size | φ50-200mm H50-350mm(can be customized) |
Filling weight | Max5000(can be customized) |
Filling accuracy | ≤100g,≤±0.5-1g ,100 – 500g,≤±1% |
Filling speed | 15-25 bottles/min(depend on the material and weight) |
Power supply | Three phase380V or single phase 220V50-60Hz(can be customized) |
Total power | 3KW |
Total weight | 350KG |
Dimension | 2000*800*1800mm |
All stainless steel structure,easy to disassemble and clean.
High precision servo motor control filling, accurate metering.
A variety of product adjustment parameters formula can be stored, ready for later use.
The replacement of spiral accessories can adapt to a variety of materials such as ultrafine powder to small particles.
Touch screen PLC control, no bottle, no filling, no cover.
Can be applied to food, medicine and corrosive chemical raw materials. Centralized dust removal, no dust pollution in the workshop.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
