Automatic Sauce Vertical Form Fill And Seal Machine
Model: LD-420L
Application:
Automatic sauce vertical form fill and seal machine, packaging solutions for bags such as sauce, miso paste, tomato sauce, olive oil, syrup, peanut butter, chocolate sauce, ketchup, shampoo, etc.
Advantages:
The product adopts advanced general control technology, can set the filling amount and filling speed through the touch screen.
Application:
Automatic sauce vertical form fill and seal machine, it is suitable for filling liquids and pastes of any fluidity in various industries.
Examples:
Sauce, olive oil, syrup, peanut butter, chocolate sauce, ketchup, juice, shampoo, fruit juice, honey, jam, paste, etc.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Sample:
| Model | LD-420L | LD-520L |
| Film Width | Max.420mm | Max.520mm |
| Bag Length | 80-300mm | 80-350mm |
| Bag Width | 60-200mm | 100-250mm |
| Range of Measurement | 150-1500ml | 2000ml |
| Film Roll Diameter | Max.320mm | Max.320mm |
| Packaging Rate | 10-60bag/min | 10-60bag/min |
| Power | 220V 50/60Hz 2KW | 220V 50/60Hz 3KW |
| Machine Size(L*W*H) | 1217*1015*1343mm | 1488*1080*1490mm |
| Machine Quality | About 650kg | About 680kg |
| Optional device | 1.Date Printing,2.Hole Punching Device,3.Air-filling Device,4.Tear Notch Device | |
1.Using color touch-screen and digitalized management,VIP5 has automactic stop and alarm advanced function when there is shortage of material or pouches.Thus it is easy to operate and convenient to maintain.
2.Adpoting Janpanses Panasonic PLC to draw the film, pneumatics to seal pouches, insures accuarte positioning, beautiful seal, so thatit helps to improve the operation stability.
3.Double-roller to exhaust air by extrusion,which can eliminate the air completely to achieve airless package.
4.One time completion on bag-making,weighing and adjusting, bagging, sealing, cutting and packing.
5.Solid and elegant work doors are waterproof and protective.The machine will stop automatically to avoid accident during prodution when workers open the doors to touch the operation part.
6.The external frame and structrue are made of stainess steel,which is clean and hygienic, up to the indicator of food hygiene quality.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
