Full Automatic Piston Quantitative Filling Machine For Sauce/ Ketchup/ Bbq Sauce
Model: LFH08
Application:
Full automatic piston quantitative filling machine (LFH08) for sauce, it is recommended for a wide variety of products including sauce, ketchup, hot sauce, bbq sauce, syrup, engine oil, lube oil, shampoo, honey, etc.
Advantages:
The product adopts advanced general control technology by using PLC touch screen, and intelligent filling, can set the filling amount and filling speed through the touch screen.
Application:
The full automatic piston quantitative filling machine (LFH08), positioning, filling and bottle-out are all automatically controlled by the PLC, conforming to the GMP standard. Applicable for medicine, food, daily chemicals, pesticides and fine chemicals, and other varieties of product filling.
Examples:
Sauce, ketchup, hot sauce, bbq sauce, syrup, engine oil, lube oil, shampoo, honey, etc.
Packaging Type:
It is suitable for various materials, various bottle types, and has a wide range of applications.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Examples:
Model | LFH08 |
Filling range | 50-1000ml |
Filling speed | <30-50 bottles/min(Base on100-500ml) |
Measurement accuracy | ±1% |
Power | 380V,220V / 3.2kw |
Working air pressure | 6-7kg/㎡ |
Gas consumption | 0.6mpa |
Weight | 1200kg |
Adopts world-famous brands of electrical and pneumatic components, low failure rate, reliable performance, long service life.
Material contact parts are made of stainless steel, easy to disassemble and assemble, easy to clean and meet the requirements of GMP.
Easy to adjust filling volume and filling speed, operated and displayed by touch screen, beautiful appearance.
With no bottle no filling function, liquid level automatic control feeding.
Piston Seals with Tetrafluorine Technology improve the wear resistance of the piston seals (service life is 12 months or more) and have a good applicability to materials.
No need to change parts, you can quickly adjust the various specifications of the shape of the bottle.
The filling head is equipped with a special leak-proof device. No wire drawing or drip leakage.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
