Fully Automatic Sauce Filling Machine For Bottle and Jar
Model: LDLJ-800
Application:
Fully automatic sauce filling machine for bottle and jar(LDLJ-800), suitable for the quantitative filling of various oils such as mayonnaise, ketchup, oil, yogurt, cream, tomato sauce, hot sauce, chili sauce, honey, etc.
Advantage:
The product adopts advanced general control technology by using a PLC touch screen, can set the filling amount and filling speed through the touch screen.
Application:
Fully automatic sauce filling machine for bottle and jar(LDLJ-800), using piston quantitative filling machine and sleeve labeling machine. It suitable for sauce, ketchup, mayonnaise, shampoo, juice, edible oil, sauce, daily necessities, medicine, etc;
Packaging Type:
Bottles, Cans, Tins, Barrel
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples:
| Model | LDLJ-800 |
| Filling Range | 5-100ml/10-300ml/50-500ml/100-1000ml/500-3000ml/1000-5000ml |
| Filling Speed | 25-40 bottles/min(base on oil) |
| Measurement Accuracy | ≤1% |
| Power | 110/220V 50-60HZ |
| Conveyor size | 2000*100mm(L*W) |
| Size of filling nozzle | OD15mm |
| Size of air compressor connector | Φ8mm |
1. Piston-type metering cylinder, servo-driven, suitable for filling thick sauce with large particles.
2. The special sauce anti-drip filling head and the enlarged rotary valve will not block or leak when filling large-grain sauce.
3. The horizontal mixing and horizontal pushing design improves the filling speed and solves the problem of uneven oil stratification.
4. Quality is reliable, simple operation, and durable, it is the ideal equipment for liquid filling.
5. PLC control, touch bottle operation, simple and convenient operation.
6. The use of internationally famous brand electrical components, performance, and stability.
7. The machine body is made of 304 stainless steel, which is easy to clean, machine is in full compliance with GMP requirements.
8. Peristaltic pump or piston pump filling system, measuring precision, convenient manipulation.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
