Automatic Quad Seal Bag/ Block Bottom Pouch Vertical Seeds Packing Machine
Model: LD-320AS
Application:
Suitable for packing all kinds of grain material, such as seeds, melon seeds, sesame seeds, snacks, candy, chips, peanuts, nutlets, preserved fruit, jelly, biscuit, etc.
Application:
Automatic quad seal pouch vertical packing machine(LD-320AS), suitable for packing all kinds of grain material, such as seeds, melon seeds, sesame seeds, snacks, candy, chips, peanuts, nutlets, preserved fruit, jelly, biscuit, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Samples:
| Model | LD-320AS | LD-380AS |
| Film width | 120-320mm | 180-380mm |
| Bag length | 50-200mm | 60-280mm |
| Bag width | 50-150mm | 60-180mm |
| Diameter of film roll | Max.300mm | Max.320mm |
| Packing speed | 35-70bag/min | |
| Measuring range | 50-500ml | 50-750ml |
| Film thickness | 0.04-0.07mm | |
| Power | 220V 50/60Hz 2.2KW | 220V 50/60Hz 2.5KW |
| Machine size(L*W*H) | 970*680*1950mm | 1100*800*2150mm |
| Machine weight | About 300kg | About 450kg |
1. Products dosing, Filling, Laminate heat sealable pouch making and sealing;
2. Stainless steel 304 structure and surface;
3. Weighing and Packaging PLC & HMI Control Integrated, More stable operation, Easy for parameter setting;
4. Simple changing of pouch former, to adapt different pouch size requirements;
5. Intelligent temperature controlling configuration, ensure the artistic and neat sealing;
6. Configure with packaging film pre-pulling device, to enable stable pouch making;
7. Easy to change the packaging film.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
