Automatic Weighing Vertical Pouch Packing Machine For Seeds
Model: LD-520A
Application:
Suitable for packaging various granular products, such as food industry, such as pet food industry, hardware industry, etc. such as seeds, popcorn, peanuts, nut, beef jerky, dry fruit, pet food, chocolate, coffee beans, nails, bolts and nuts, buckles, etc.
Application:
Automatic weighing vertical pouch packing machine for popcorn, can be used for the packaging of various granular items, such as seeds, food, medicine, the chemical industry, and other fields.
Examples:
Pet food industry, hardware industry, etc. such as popcorn, peanuts, nut, beef jerky, dry fruit, pet food, chocolate, coffee beans, nails, bolts, and nuts, etc.
Kindly Reminder:
We have an experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Examples:
| Model | LD-420 | LD-520 | LD-720 | LD-900 | LD-1050 | LD-1200 |
| Film Thickness | 0.04-0.08mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm | 0.04-0.12mm |
| Bag Length | 80-300mm | 80-350mm | 100-500mm | 100-600mm | 100-800mm | 100-1000mm |
| Bag Width | 60-200mm | 100-250mm | 180-350mm | 260-430mm | 290-505mm | 290-580mm |
| Film Roll Diameter | Max.320mm | Max.320mm | Max.320mm | 400mm | 400mm | 400mm |
| Pakaging Rate | 5-60bag/min | 5-60bag/min | 5-55bag/min | 5-20bag/min | 5-20bag/min | 5-20bag/min |
| Film Width | Max.420mm | Max.520mm | 150-Max.720mm | Max.900mm | Max.900mm | Max.1200mm |
| Measurement Range | 150-1500ml | 5-2000ml | 4000ml | 1-25L | 1-25L | 1.5L-45L |
1. The new design, beautiful appearance, the structure is more reasonable, more advanced technology.
2. English and Chinese screen display. PLC control, servo motor, very easy to operate. Do not need to stop the machine to adjust any parameters.
3. Fully automatic bag forming, dosing Filling, sealing, coding, conveying, and counting can be finished in one operation, most labor-saving equipment.
4. High-quality stainless steel, suitable for GMP, good for food packaging with high standards.
5. Horizontal, vertical temperature control, suitable for various of mix film, and PE film packing materials.
6. Pocket diversification, can provide customers with pillow bags, angled bags, hanging-hole bags, vertical bags, punched bags, etc.
7. A variety of automatic alarming protective functions, maximum limit to reduce wear and tear.
8. Double sever motors, drawing film position accurately, and the speed is faster.
9. Temperature independent control system, precision gets to ±1°C.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
