High-Efficiency Stainless Steel Turntable Shampoo Filling Capping Integrated Machine
Model: LD-ALF01
Application:
Shampoo filling and capping machine integrates filling, collaring and screwing cap functions, it can be used to fill shampoo, toner, emulsion, nourishing cream, , etc. With easy operation, this machine can help you save time and reduce labor tensity.
Application:
High-efficiency stainless steel turntable shampoo filling capping integrated machine, integrates filling, collaring and screwing cap functions.
Examples:
Shampoo, toner, emulsion, nourishing cream, , etc. With easy operation, this machine can help you save time and reduce labor tensity.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Sample:
Product Name | High-Efficiency Stainless Steel Turntable Cosmetic Jars Cream Filling Capping Integrated Machine |
Model | LD-ALF01 |
Filling Range | 50-1000ml(Customizable) |
Filling Speed | 15-50 bottle/min |
Measurement accuracy | ±1% |
Power | 2 KW |
Working power supply | 220V、50Hz |
Working pressure | 0.6-0.8MPa |
Weight | 500kg |
Size | L4000*W1320*H2090(mm) |
Features:
1. Automatic air cleaning- filling- inner cap inserting- capping.
2. Air cleaning system: cleaning dust and impurities.
3. Filling system: Servo motor control, rotary vale filling. High filling accuracy, suitable filling high foam liquid, can
self-suck when filling water type liquid.
4. The hopper is with liquid level detection system. Simple operation and adjust
5. Adjustable molds: suitable for different sizes of bottles
6. Screw filling system: suitable for any of the screw caps. The cap contacting material is soft silicone, this material won’t scrap cap
7. Anyone can skillfully operate without training
8.Five Servo Motor Controlling High Efficicency
Filling Line Composition:
1.24 Bottle Holding Mechanism;
2.Air Blow Mechanism;
3.Servo Filling Mechanisim;
4.80L Storage Hopper 80L;
5.Gland Mechanisnm for Inner Caps;
6.Screw Capping Mechanism;
7.Finished Bottle Pick Up Mechanism;
8.Round Bottle Labeling machine auto labeling;
4.Inject Printer for batch, exp date, production date;
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
