Semi-Automatic Granular Strip and Flake Solid Materials Packaging Machine
Model: LD-320A
Application:
Semi-automatic granular, strip and flake solid materials packaging machine for sugar, salt, candy, chips, peanuts, nut , preserved fruit, biscuit, almond, chocolate, beef jerky, dilatant foodstuff, hardware and plastic can be weighed by theration.
Advantage:
The measuring cup is used to accurately control the weight or capacity of the product.
Application:
Semi-automatic granular strip and flake solid materials packaging machine, the measuring cup is used to accurately control the weight or capacity of the product.
Examples:
Sugar, salt, candy, chips, peanuts, nut , preserved fruit, biscuit, almond, chocolate, beef jerky, dilatant foodstuff, hardware and plastic can be weighed by theration.
Kindly Reminder:
We have experienced team of R & D engineers who can customize packaging solutions according to your product characteristics.
Packaging Exambers:
Model | LD-320 | LD-380 |
Film width | 120-320mm | 180-380mm |
Bag length | 50-200mm | 60-280mm |
Bag width | 50-150mm | 60-180mm |
Diameter of film roll | Max.300mm | Max.320mm |
Packing speed | 35-70bag/min | |
Measuring range | 50-500ml | 50-750ml |
Film thickness | 0.04-0.07mm | |
Power | 220V 50/60Hz 2.2KW | 220V 50/60Hz 2.5KW |
Machine size(L*W*H) | 970*680*1950mm | 1100*800*2150mm |
Machine weight | About 300kg | About 450kg |
1.Products dosing, Filling, Laminate heat sealable pouch making and sealing;
2.Stainless steel 304 structure and surface;
3.Weighing and Packaging PLC & HMI Control Integrated, More stable operation, Easy for parameter setting;
4.Simple changing of pouch former, to adapt different pouch size requirement;
5.Intelligent temperature controlling configuration, ensure the artistic and neat sealing;
6.Configure with packaging film pre-pulling device, to enable stable pouch making;
7.Easy to change the packaging film.
We have many customer packaging case videos, please feel free to contact us to obtain your product packaging case videos.
Get Price & More Detail
